| Product Overview | |
|---|---|
| Product Type | Victron Energy Quattro Inverter/Charger |
| Description | The Quattro is a combined inverter and battery charger with two AC inputs and two AC outputs. It automatically connects to the active power source and provides uninterrupted power transfer in less than 20 milliseconds. Designed for off-grid, backup, marine, and energy storage applications. |
| Available Models | 3000VA, 5000VA, 8000VA, 10000VA, 15000VA |
| Key Features | |
| Dual AC Inputs | Connects to two independent AC sources such as grid power and a generator, automatically selecting the active source. |
| Dual AC Outputs | Main output provides uninterrupted power transfer. Secondary output operates only when AC power is available, ideal for non-essential loads such as water heaters and air conditioners. |
| PowerAssist Technology | Prevents overload of limited AC sources by reducing battery charging and supplementing power from the battery when required. |
| PowerControl | Allows current limits to be set on each AC input, preventing generator or grid overload. |
| Pure Sine Wave Output | Provides clean and stable power suitable for sensitive electronics and appliances. |
| Adaptive Charging | Optimizes battery charging performance and battery lifespan. |
| Scalability & System Expansion | |
| Parallel Operation | Up to 6 Quattro units can operate in parallel for higher power output. |
| Split Phase Capability | Supports 120-0-120V split phase configurations. Up to 30kW / 36kVA can be achieved with parallel units. |
| Three Phase Capability | Three units can be configured for three-phase output, with up to 144kW / 180kVA inverter power available through parallel configurations. |
| Monitoring & Control | |
| Local Monitoring | Supports Battery Monitor, Multi Control Panel, GX devices, smartphones, tablets, laptops, and PCs. |
| Remote Monitoring | Monitor and control systems remotely through GX devices and the VRM platform. |
| Remote Configuration | System settings can be accessed and modified remotely when connected via Ethernet and GX devices. |
| Solar & Energy Applications | |
| Solar Compatibility | Compatible with off-grid, grid-connected PV systems, MPPT solar chargers, and alternative energy systems. |
| Grid Failure Support | Continues supplying AC power during grid outages with seamless transfer to battery power. |
| Configuration Options | |
| Stand-Alone Systems | Quick configuration via DIP switch settings. |
| Advanced Systems | Supports VE.Bus Quick Configure, VE.Bus System Configurator, and Assistant software for complex installations. |
| Technical Specifications | |
| Brand | Victron Energy |
| Input Voltage | 12V |
| Output Voltage | 110V |
| Current | 200A |
| Power Output | 4000W |
| Inverter Type | Pure Sine Wave |
| Region | North America |
| Warranty | 5 Years |
| Weight | 34 kg |
| Dimensions (W × D × H) | 280 × 350 × 470 mm |
-20%
Victron Energy Quattro 12V 5000VA 120V Inverter Charger (220A Charge / Dual AC Input) – QUA125021100
Original price was: $5,999.43.$4,799.54Current price is: $4,799.54.
In stock
| Weight | 74.97 lbs |
|---|---|
| Dimensions | 11.02 × 13.78 × 18.5 in |
| Rating | 5000 |
| Voltage | 120V |
| model | QUA125021100 |
| Brand | |
| Warranty | 5 years standard warranty against manufacturers defects |
| Manufacturer | Victron Energy B.V. |
