Specification Details
| Parts per Unit | 100 |
|---|---|
| Features | Copper stranded conductor for maximum conductivity, tinned for corrosion resistance, gives extra protection in high corrosive marine applications, Meets DOT and Coast Guard specifications for electrical systems |
| Application | Marine Applications |
| Gauge | 16 |
| Conductor Material | Copper |
| Cable Nominal Outer Diameter | |
| Insulation Material | PVC |
| Insulation Thickness | 0.03 in |
| Pack Type | Roll |
| Prop 65 Item | DEHP, DINP |
| SAE | No |
| Strand Count | 26 |
| Strand Gauge | 30 |
| Subject to Prop 65 | Yes |
| Temperature Range (°C) | dry 105°C, wet 75°C |
| Temperature Range (°F) | dry 221°F, wet 167°F |
| UL / CSA | Yes |
| Voltage | 600 V |
| Works With | Automotive Connections |
| Conductor Plating Material | Tinned |
| Brand | Not branded |
| Cable Nominal Outer Diameter | 0.12 in |
| Color | Green |
| Product Length | 3.50 in |
| Product Width | 3.50 in |
| RoHS Compliant | Yes |
| SKU | 251305, 251305-100 |
| Cable Length | 100 ft |
| Product Weight | 1.25 lb |
| Country of Origin | USA |
