APC by Schneider Electric Back-UPS 650VA, 120V,1 USB charging port, Canada

APC by Schneider Electric Back-UPS 650VA, 120V,1 USB charging port, Canada
General Information

Manufacturer:

Schneider Electric SA

Manufacturer Part Number:

BVN650M1-CA

Manufacturer Website Address:

http://www.schneider-electric.com

Brand Name:

APC by Schneider Electric

Product Line:

Back-UPS

Product Name:

Back-UPS 650VA, 120V,1 USB charging port, Canada

Marketing Information:

Battery Backup & Surge Protector for Electronics and Computers The Back-UPS battery backup offers guaranteed power and surge protection for wireless networks, computers, gaming consoles and other electronics in your home or business. Models supply battery backup during outages and unsafe voltage fluctuations, as well as provide protection from damaging surges and spikes. They’re available in ‘tower’ or ‘floor’ styles, and together with a variety of standard features, they are the perfect choice to protect your data and keep you connected.

Packaged Quantity:

1 Each

Product Type:

Line-interactive UPS

Technical Information

Plug/Connector Type:

NEMA 5-15P

Receptacle Detail:

7 x NEMA 5-15R

Number of Surge-only Outlets:

2

Transfer Time:

6 ms

Application/Usage:

ElectronicComputerMission Critical EquipmentNetwork EquipmentGaming Console

Power Description

Load Capacity (VA):

650 VA

Load Capacity (Watt):

360 W

Input Voltage:

120 V AC

Input Voltage Range:

88 V AC – 143 V AC

Output Voltage:

120 V AC

Input Frequency:

60 Hz

Output Frequency:

60 Hz

Waveform Type:

Stepped Approximated Sine Wave

Surge Energy Rating:

490 J

Management

Alarm:

On BatteryLow BatteryOverload

Controls/Indicators

Status Indicators:

LED Status Display: On Line On Battery

Interfaces/Ports

USB (HID Compliant) Port:

Yes

Battery Information

Backup/Run Time (Full Load):

1.90 Minute

Backup/Run Time (Half Load):

10 Minute

Replaceable Battery:

Yes

Environmental Conditions

Maximum Operating Temperature:

104°F (40°C)

Storage Temperature:

5°F (-15°C) – 113°F (45°C)

Maximum Operating Elevation:

6666.01 ft (2031800 mm)

Maximum Storage Elevation:

10000 ft (3048000 mm)

Physical Characteristics

Height:

5.47″ (139 mm)

Width:

4.13″ (105 mm)

Depth:

10.79″ (274 mm)

Form Factor:

Tower

Weight (Approximate):

3.10 kg

Miscellaneous

Package Contents:

Back-UPS 650VA, 120V,1 USB charging port, Canada User Manual

Recycled:

No

Assembly Required:

No

Energy Star:

Yes

Environmental Certification:

China Environmental United Certification Center (CEC)

Warranty

Limited Warranty:

3 Year
