SPECIFICATIONS
| ELECTRICAL | ||
| Current Rating Amperes | UL 1977 | CSA |
| • SB®50 | 120 | 50 |
| • SB®120 | 240 | 130 |
| • SB®175 | 280 | 175 |
| MECHANICAL | ||
| Environmental Protection | ||
| • SB®50, SB®120 and SB®175 | IP64 | |
| Wire Size Range | AWG | mm² |
| • SB®50 | 16 to 6 | 1.3 to 13.3 |
| • SB®120 | 10 to 1 | 5.3 to 42.4 |
| • SB®175 | 12 to 1/0 | 3.3 to 53.5 |
| Operating Temperature | F | C |
| • SB® Connector Housing | -4° to 221° | 20° to 105° |
| • SB® Connector Housing (CR)* | -40° to 221° | -40° to 105° |
| • SB® Environmental Boot | -40° to 275° | -40° to 135° |
| Mating Cycles | Connector in Boot | |
| • SB®50 | 1,500 | |
| • SB®120 | 1,500 | |
| • SB®175 | 1,500 | |
| MATERIALS – SB®50, SB®120 and SB®175 | ||
| • SB® Connector Housing | PC | |
| • SB® Connector Housing (CR) * | PC/PBT | |
| • SB® Environmental Boot | TPE | |
| Flammability Rating | ||
| • UL94 | V0 | |
| UV and Ozone Resistant | Yes | |
