| Product Specifications | |
|---|---|
| Product Series | AGM-S |
| Product Type | AGM Battery |
| Product Count | 1 Battery |
| Voltage | 12V |
| BCI Group | 27 |
| Cells | 6 |
| Capacity | 105 Ah (20 Hour Rate) |
| Maximum Capacity | 116 Ah (100 Hour Rate) |
| Warranty | See Warranty Terms |
| Performance Specifications | |
|---|---|
| Cold Cranking Amps (CCA) | 680 A @ 0°F / -18°C |
| Marine Cranking Amps (MCA) | 900 A @ 32°F / 0°C |
| Reserve Capacity (RC @ 25A) | 180 Minutes |
| Reserve Capacity (RC @ 75A) | 43 Minutes |
| Internal Resistance | 4 mΩ |
| Self-Discharge Rate | Less than 2% per month at 25°C (77°F) |
| Charging Specifications | |
|---|---|
| Charge Voltage Range | 14.7V @ 25°C (77°F) |
| Float Voltage Range | 13.8V @ 25°C (77°F) |
| Recommended Charge Current | 20 A |
| Maximum Charge Current | 35 A |
| Terminal Type | F12 (M8) with TP08 Adapter (+21mm) |
| Included Hardware | M8 Stainless Bolts, Washers & TP08 Adapter |
| Capacity Ratings | |
|---|---|
| 100 Hour Rate | 116 Ah @ 1.16 A |
| 20 Hour Rate | 105 Ah @ 5.25 A |
| 10 Hour Rate | 95 Ah @ 9.5 A |
| 5 Hour Rate | 86 Ah @ 17.2 A |
| Temperature Performance | |
|---|---|
| 40°C (104°F) | 102% Capacity |
| 25°C (77°F) | 100% Capacity |
| 0°C (32°F) | 85% Capacity |
| -15°C (5°F) | 65% Capacity |
| Physical Specifications | |
|---|---|
| Weight | 30 kg (66 lbs) |
| Length | 30.7 cm (12.09″) |
| Width | 16.9 cm (6.65″) |
| Height Including Terminals | 21.5 cm (8.46″) |
| Construction | |
|---|---|
| Container Material | ABS |
| Cover Material | ABS |
| Handles | Rope / Plastic Handle |
| Discharge Specifications | |
|---|---|
| Cut-Off Voltage | 1.75 VPC |
| Discharge Rate (1 Hour) | 55.5 A |
| Discharge Rate (2 Hours) | 32.9 A |
| Discharge Rate (3 Hours) | 25.8 A |
| Discharge Rate (5 Hours) | 17.5 A |
| Discharge Rate (8 Hours) | 12.2 A |
| Discharge Rate (10 Hours) | 10.1 A |
