Specification Details
| Parts per Unit | 1, 5 |
|---|---|
| Features | 2:1 Shrink Ratio, Conforms to DOD Mil-I-23053/5 Class 1 and 2, also meets UL-224 125°C specification, Economical and ideal for general purpose applications, Sealant free single wall construction |
| Gauge | 10, 6, 8 |
| Body Material | Polyolefin |
| Flame Retardant | Yes |
| Nominal Wall Thickness | 0.02 in |
| Pack Type | Bag |
| Post Shrink Wall Thickness | 1/32 in |
| SAE | No |
| Shrink Ratio | 2:1 |
| Subject to Prop 65 | No |
| Temperature Range (°C) | -55 to 135°C |
| Temperature Range (°F) | -67 to 275°F |
| Tensile Strength | 10.4 PSI |
| UL / CSA | No |
| Adhesive | No |
| Waterproof | No |
| Brand | PrimaryTube |
| Color | Yellow |
| Product Length | 48.00 in, 6.00 in |
| RoHS Compliant | Yes |
| SKU | 5668-001YW, 5668-005YW, 5668YW |
| Expanded Diameter | 3/8 in |
| Shrunk Diameter | 3/16 in |
| Application | Battery Connectors |
| Country of Origin | China |
