Specification Details
| Parts per Unit | 10, 2, 50 |
|---|---|
| Features | 4 GA cable is 7”, Converts top post to side terminal, Polarity specific, sold in pairs |
| Application | Light Duty Cars, RVs, Trucks, Vans |
| Gauge | 4 |
| Connection Type | Clamp to Cap Nut |
| Cable Nominal Outer Diameter | |
| Insulation Material | PVC |
| Insulation Thickness | 0.06 in |
| Pack Type | Bag, Box |
| Polarity | Negative, Positive |
| Prop 65 Item | DEHP, DINP, Lead |
| Strand Count | 70 |
| Subject to Prop 65 | Yes |
| Termination Material | Lead |
| Termination Material Plating | |
| Thimble | No |
| UL / CSA | No |
| Brand | Not branded |
| Cable Nominal Outer Diameter | 0.28 in |
| Color | Black, Red |
| Product Length | 6.75 in |
| RoHS Compliant | Yes |
| Temperature Range (°C) | -50 to 105°C |
| Temperature Range (°F) | -58 to 221°F |
| Termination Material Plating | Tin |
| Works With | Side Posts, Top Post |
| SKU | 5505, 5505-010, 5505-050, 5505-2002 |
| Assembly Cable Length | 6.75 in |
| Product Weight | 0.98 lb |
| Tristrip Statement | Strip .91″ (23 mm) minimum of insulation from end, fully insert in connector & crimp at two locations. |
| Tristrip Statement / Spanish | Strip 0.91 ” ( 23 mm ) como mínimo de aislamiento del extremo , totalmente insertar en el conector y engarzado en dos lugares. Bande de 0,91 ” ( 23 mm ) |
| UL Statement | QuickCable UL Listed connectors are for use on stranded copper wire only. |
| Country of Origin | USA |
