Specification Details
| Parts per Unit | 5, 50 |
|---|---|
| Features | Connectors of different cable gauges can be mixed for maximum application and layout flexibility, Stud battery applications require use of 3/8″–16 closed cap nut, Use with stud batteries, enables multiple battery hook up Stackable, 24-position anti-rotation teeth bite into lead for positive hold |
| Application | Crimp, Solder |
| Includes | Fasteners |
| Gauge | 2/0 |
| Pack Type | Bag |
| Plating Material | Tin |
| SAE | J163, J1811 |
| Stud Hole Size | 3/8 in |
| Subject to Prop 65 | No |
| Termination Material | Copper |
| Termination Method | Crimp |
| UL / CSA | Yes |
| Works With | Stud Batteries |
| Brand | QUICK |
| Color | Silver |
| Product Length | 2.50 in |
| Product Width | 1.68 in |
| Production Process | Cast |
| RoHS Compliant | Yes |
| SKU | 4520-005F, 4520-050F, 4520F |
| Product Height | 0.37 in |
| Product Weight | 0.13 lb |
| Tristrip Statement | Strip .91″ (23mm) minimum of insulation from end, fully insert in connector & crimp at two locations. |
| Tristrip Statement / Spanish | Remueva por lo menos 23 mm (0.91 pulgadas) de aislamiento desde un extremo, inserte por completo en el conector y prense en dos lugares. |
| UL Statement | QuickCable UL Listed connectors are for use on stranded copper wire only. |
| Country of Origin | USA |
