Specification Details
| Parts per Unit | 100, 1000, 20, 25 |
|---|---|
| Features | Copper stranded conductor for maximum conductivity, For use at 60V or less, Meets or exceeds SAE J1128, PVC insulation resists abrasion, fuel, oil, acid and salt |
| Application | General Purpose |
| Gauge | 14 |
| Conductor Material | Copper |
| Cable Nominal Outer Diameter | |
| Insulation Material | PVC |
| Insulation Thickness | 0.023 in |
| Pack Type | Roll |
| Prop 65 Item | DEHP, DINP |
| SAE | J1128 |
| Strand Count | 19 |
| Strand Gauge | 27 |
| Subject to Prop 65 | Yes |
| Temperature Range (°C) | -40 to 80°C |
| Temperature Range (°F) | -40 to 176°F |
| UL / CSA | No |
| Voltage | 60 V |
| Works With | Automotive Connections |
| Brand | Not branded |
| Cable Nominal Outer Diameter | 0.117 in |
| Color | Red |
| Product Length | 3.50 in, 5.12 in, 6.44 in |
| Product Width | 3.50 in, 3.87 in, 6.44 in |
| RoHS Compliant | Yes |
| SKU | 230402, 230402-025, 230402-100, 230402-1000, 230402-2020 |
| Cable Length | 100 ft, 1000 ft, 20 ft, 25 ft |
| Product Weight | 0.42 lb, 1.75 lb, 19.00 lb |
| Country of Origin | USA |
