Specification Details
| Parts per Unit | 10, 50 |
|---|---|
| Features | Can be crimped or soldered, Flared barrels for easy installation on cables, Seamless 100% copper tube construction |
| Application | General wiring as well as starter or ground connections |
| Gauge | 8 |
| Pack Type | Bag |
| SAE | No |
| Stud Hole Size | 1/2 in |
| Subject to Prop 65 | No |
| Termination Material | Copper |
| Termination Method | Crimp |
| UL / CSA | Yes |
| Works With | Side Posts |
| Brand | Max |
| Color | Copper |
| Product Length | 1.31 in |
| Product Width | 0.67 in |
| Product Type | Straight lug |
| RoHS Compliant | Yes |
| SKU | 105019, 105019-010, 105019-050 |
| Product Height | 0.31 in |
| Product Weight | 0.01 lb |
| Tristrip Statement | Strip .55″ (14mm) minimum of insulation from end, fully insert in connector & crimp at two locations. |
| Tristrip Statement / Spanish | Remueva por lo menos 14 mm (0.55 pulgadas) de aislamiento desde un extremo, inserte por completo en el conector y prense en dos lugares. |
| UL Statement | QuickCable UL Listed connectors are for use on stranded copper wire only. |
| Country of Origin | China |
