Specification Details
| Parts per Unit | 1, 25 |
|---|---|
| Features | All have a standard 3/8″ stud hole, Antimonial lead connectors resist corrosion, die cast process seals copper wire from acid fumes and corrosive salts, Copper conductor for maximum conductivity, Meets or exceeds SAE specifications, ideal for OEM replacement, Standard Retail Cables, Temperature range: 221°F (105°C) to -58°F (-50°C), Tinning of copper wire before casting ensures durable bond between wire and connector |
| Application | Light Duty Cars, RVs, Trucks, Vans |
| Gauge | 4 |
| Connection Type | Clamp to Lug, Clamp to Thimble |
| Cable Nominal Outer Diameter | |
| Insulation Material | PVC |
| Insulation Thickness | 0.06 in |
| Pack Type | Bag, Box |
| Polarity | Positive |
| Prop 65 Item | DEHP, DINP, Lead |
| RoHS Item | Lead |
| SAE | Yes |
| Strand Count | 70 |
| Stud Hole Size | 3/8 in |
| Subject to Prop 65 | Yes |
| Temperature Range (°C) | -50 to 105°C |
| Temperature Range (°F) | -58 to 221°F |
| Termination Material | Copper, Lead, Steel |
| Termination Material Plating | |
| Thimble | No, Yes |
| UL / CSA | No |
| Brand | Not branded |
| Cable Nominal Outer Diameter | 0.28 in |
| Color | Red |
| Product Length | 37.00 in |
| RoHS Compliant | No |
| Termination Material Plating | Tin |
| Works With | Side Posts, Top Post |
| SKU | 8037, 8037-001, 8037-025, 8037T-001 |
| Assembly Cable Length | 37.00 in |
| Product Weight | 0.77 lb |
| Country of Origin | USA |
