Specification Details
| Parts per Unit | 5 |
|---|---|
| Features | Copper alloy, tin plated for added conductivity and corrosion resistance, Exceeds SAE standards, J163 and J1811, For crimp or solder applications, For preassembled cable options – see QuickLinks, Made in USA, Precise dimensions to fit battery posts for maximum contact |
| Application | Heavy Duty |
| Gauge | 8 |
| Pack Type | Bag |
| Plating Material | Tin |
| SAE | J163, J1811 |
| Stud Hole Size | 1/2 in |
| Subject to Prop 65 | No |
| Termination Material | Copper |
| Termination Method | Crimp |
| UL / CSA | Yes |
| Works With | Side Posts |
| Brand | QUICK |
| Color | Silver |
| Product Length | 2.00 in |
| Product Width | 0.75 in |
| Product Type | Straight lug |
| Production Process | Cast |
| RoHS Compliant | Yes |
| SKU | 4808-005H, 4808H |
| Product Height | 0.50 in |
| Product Weight | 0.16 lb |
| Tristrip Statement | Strip .91″ (23mm) minimum of insulation from end, fully insert in connector & crimp at two locations. |
| Tristrip Statement / Spanish | Remueva por lo menos 23 mm (0.91 pulgadas) de aislamiento desde un extremo, inserte por completo en el conector y prense en dos lugares. |
| UL Statement | QuickCable UL Listed connectors are for use on stranded copper wire only. |
| Country of Origin | USA |
