Electrical Specifications
| Specification | Value |
|---|---|
| Nominal Voltage | 12V |
| C100 | 38 Ah |
| C20 | 35 Ah |
| C5 | 30 Ah |
| CCA | 438 Amps |
| CA or MCA | 525 Amps |
| PHCA | 975 Amps |
| Internal Resistance | 9.4 mΩ |
Mechanical Specifications
| Specification | Value |
|---|---|
| Group Size | U1, H-12 |
| Terminal Type | M6 + TP26 (SAE) |
| Terminal Torque | 3.3 – 4.8 Nm / 40 – 57.5 in-lbs / 4.5 – 6.5 ft-lbs |
| Height (w/ terminal) | 7.56 in / 192 mm |
| Height (case only) | 6.10 in / 155 mm |
| Width | 5.16 in / 131 mm |
| Length | 7.72 in / 196 mm |
| Weight | 24.91 lbs / 11.3 kg |
| Case Type | ABS Plastic |
