| ELECTRICAL CHARACTERISTICS | |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 30Ah |
| Energy | 1536Wh |
| Resistance | £60mW |
| Self Discharge | <3% / Month |
| Cell configuration | 16S2P |
| CHARGE PERFORMANCE | |
| Maximum Charge Current | 30A |
| Charge Voltage | 57.6V +/- 0.2V |
| DISCHARGE PERFORMANCE | |
| Continuous Current | 60A |
| Max. Pulse Current | 80A (10S) |
| Disc. Cut-Off Voltage | 44.0V |
| TEMPERATURE PERFORMANCE | |
| Charge Temperature | 0°C to 45°C (32F to 113F) |
| Discharge Temperature | -20°C to 60°C (-4F to 140F) |
| MECHANICAL PERFORMANCE | |
| Dimension (L x W x H) | 260 x 180 x 247 mm |
| Weight | 12 +/- 0.5kg (24.46lbs) |
| Case Material | ABS |
| Cycle Life | >2000 cycles @ 1C 80% DOD |
| Series Connect | Can not connect in series |
| Parallel Connect | Max. 4 batteries connected |
| COMPLIANCE | |
| Shipping Classifications | UN3480, CLASS 9 |
| MAINTENANCE | |
| Routine Charging | Charge and discharge every 3 months |
| Storage Temperature | 0°C to 40°C (32F to 104F) |
| Weight | 27.5 lbs |
|---|---|
| Dimensions | 10.24 × 7.08 × 10.71 in |
| Features | Drop-In SLA/AGM Replacement, Fast Charging Compatible, High Discharge Rate (Starter Use), Rack-Mount Design (Telecom, Smart BMS, UPS) |
| Form Factor | Prismatic Cell Lithium |
| Battery Type | Lithium Iron Phosphate (LiFePO₄) |
| Chemistry | Lithium Iron Phosphate (LiFePO₄) |
| Application | Club Car, Golf Carts (EZ-GO, Small Electric Vehicles, Yamaha) |
| Cycle Life | 4000+ cycles @ 80% DoD |
| Terminal Type | 5/16" Stud |
| Battery Group Size | GC2 |
| Part No | VTL48-30 |
| Warranty | 10 Years |
| Voltage | 48 |
| Reserve Capacity (RC) | 60 min |
| Capacity (Ah) | 30 |
| Brand |
