UNI-T UT256B Fork Meter

DC/AC voltage: 1000V/750V; DC/AC current: 200A; Resistance: 60MΩ; Capacitance: 60mF; Frequency: 10KHz; NCV; True-RMS
Specifications of UT256 Series 200A True RMS Fork Meters

Specifications Range UT256A UT256B
Certifications CE/RoHS/cETLus
Safety ratings CAT II 1000V, CAT III 600V
AC current (A) 200A ±(1.8%+5) ±(2.5%+5)
DC current (A) 200A ±(2.5%+5)
AC voltage (V) 750V ±(1.2%+3)
1000V ±(1.2%+3)
DC voltage (V) 1000V ±(0.8%+3) ±(0.8%+3)
Resistance (Ω) 60MΩ ±(1%+2) ±(1%+2)
Capacitance (F) 60mF ±(4%+20)
Frequency (Hz) 10~10kHz ±(0.1%+5)
Display count 6000 6000
Diode test About 3V √
NCV √ √
Zero mode √
Relative mode √
General Characteristics
Power 1.5V battery (LR6) x 2
Display UT256A: 35mm x 26mm; UT256B: 36.5mm x 24mm
Product net weight 248g
Product size UT256A: 217mm x 58.8mm x 38.5mm; UT256B: 210mm x 53mm x 35mm
Standard accessories Batteries, test leads, English manual
Standard individual packing Gift box, carrying bag
Standard quantity per carton 20pcs
Standard carton measurement 485mm x 310mm x 205mm
Standard carton gross weight 9.5kg
