UNI-T UT120A Pocket Size Type Digital Multimeter

AC/DC voltage test: 600V; Resistance test: 40MΩ; Frequency: 100KHz; Temperature: -55℃~500℃;
Specifications of UT120 Series Pocket Size Digital Multimeters

Specifications Range UT120A UT120B UT120C
DC voltage (V) 600V ±(0.8%+1) ±(0.8%+1) ±(0.8%+1)
AC voltage (V) 600V ±(1.2%+3) ±(1.2%+3) ±(1.2%+3)
DC current (A) 400mA ±(1%+3)
AC current (A) 400mA ±(1.5%+5)
Resistance (Ω) 40MΩ ±(1%+2) ±(1%+2) ±(1%+2)
Capacitance (F) 100μF ±(4%+3) ±(4%+3)
Frequency (Hz) 10MHz ±(0.5%+3) ±(0.5%+3) ±(0.5%+3)
Features
Display count 4000 4000 4000
Auto range √ √ √
Duty cycle 0.1%~99.9% √ √ √
Diode √ √ √
Auto power off Around 30 minutes √ √ √
Continuity buzzer √ √ √
Low battery indication ≤2.4V √ √ √
Data hold √ √ √
Relative mode √ √ √
Input impedance for DCV Around 10MΩ √ √ √
General Characteristics
Power 3V battery (CR2032)
Display 43mm x 22mm
Product color Red and grey
Product net weight 76g
Product size 110mm x 58.2mm x 10.8mm
Standard accessories Battery, carrying case
Standard individual packing Blister, English manual
Standard quantity per carton 100pcs
Standard carton measurement 750mm x 275mm x 490mm (0.1CBM per export carton)
Standard carton gross weight 20kg
