Cotek SD2500-224 SCHUKO 2500W Pure Sine Wave Inverter with Schuko Socket Type 24VDC 230VAC Schuko + Hardwire output

Cotek > 2500 Watt 24 VDC Pure Sine Wave Inverter with Schuko Socket Type
The SD series is a pure sine wave inverter designed especially for the most demanding mobile and off-grid applications. SD series provides up to 90% of high efficiency and wide operating temperature range (from -20?C to +60?C) designed for many harsh environments.

The N+X parallel redundancy framework design can greatly improve the power system’s flexibility and thus the system’s volume and weight are remarkable reduced. SD series features a built-in transfer switch and synchronized operation with utility AC source. SD series can be used for N+1 (N?14) redundancy and the ability of enlarge the capacity (Users can install maximum 15 units of inverters together in parallel in order to provide the power expansion). SD series also provides complete protection functions including Input low voltage, Overload, Short circuit, Low battery alarm, Input over voltage and over temperature.

Application
Home and office appliances, portable power equipment, vehicle, yacht and off-grid solar power systems…etc.

Specifications
Model SD2500-224 (Schuko)
Series SD2500
Manufacturer Cotek
Additional Details Data Sheet
Mechanical
Type Pure Sine Wave
Operating Temperature Range -20?C to +60?C
Cooling Load & Thermal Control Fan
Dimensions (W x H x D) 11.146″ x 5.056″ x 19.527″
Weight 17.64 lbs
Shipping Method 21 lbs
DC Input
Input Battery Voltage 24 VDC
Max Current < 1.8 A AC Input AC Output Voltage 200 / 220 / 230 / 240 VAC +-12.5% Frequency Selectable 50 / 60 Hz Circuit Breaker 20A Output Maximum Output Power 2500 W Peak Power 3000 W Frequency 50 / 60 Hz +-0.1% Features Schuko Socket Type for International 230 VAC Parallel redundancy design for power expansion Multiple industrial applications that create 1 W / 3? 4W power systems Automatic master mechanism to eliminate single point failure and optimize reliability Built-in ATS and AC circuit breaker Optional STS module, transfer time less 4ms. RS-232 communication Input & output fully isolation Output voltage / power saving mode selectable by DIP switch or remote control (CR-10) Input Protection: Reverse Polarity (Fuse) / Under Voltage / Over Voltage Output Protection: Short Circuit / Overload / Over Temperature / Over Voltage
