UNI-T UTi32 Heavy Duty thermal imager

32×32, -20~1000℃, 30º×30º, 9Hz, 2.4′ LCD

Specifications of UTi32

Technical Data
IR resolution (Pixels) 32×32
Display 2.4″ IPS (480×320)
Field of view(FOV) 30°×30°
Thermal sensitivity(NETD) 0.15℃
Frame rate ≤9Hz
Spectral range 8~14µm
Focus Focus free
Temperature measurement range -20℃ ~ 1000℃
Accuracy ±2℃ or ±2% whichever is greater
Emissivity 0.01~1.00 adjustable (0.95 default)
Functions
Color palettes 3
(Ironbow, Rainbow, Black hot)
Image modes Thermal,Visual image,Fusion
Digital camera resolution 640×480
Hi/Lo temperature alarm Icon
Software analysis PC
General Characteristics
Battery Fixed Li-ion battery (3.7V 2600mAh)
Battery operation time ≥7 hours
USB Type-C
Storage 16G Mirco SD card
Image/Video storage format BMP
Certificates CE,UKCA,FCC,RoHS
Product net weight 301g
Product size 205mmx124mmx65mm
Packing Details
Standard accessories Micro SD card, Type-C USB cable, English manual, Documents Download Operation Guide
Standard individual packing Gift box
Standard Qty per carton 5
Standard carton size 500mm×275mm×190mm
Standard carton G.W. 4Kg
