UNI-T UT202T Smart Digital Clamp Meter

AC current: 600A; DC/AC voltage: 600V; Resistance: 6MΩ; Frequency: 1000Hz; Capacitance: 100mF;
Specifications of UT200R Series 400A/600A Digital Clamp Meters

Specifications Range UT201R UT202R UT202F UT203R UT204R
AC current (A) 0.04~400A ±(2%+10) ±(2%+10) ±(2%+5)
0.06~600A ±(2%+10) ±(2%+5)
AC current frequency (Hz) 50Hz~100Hz ±(1%+5) ±(1%+5) ±(1%+5)
DC current (A) 0.04~400A ±(2%+5)
0.06~600A ±(2%+5)
AC voltage (V) 600V ±(0.8%+5) ±(0.8%+5) ±(0.8%+5) ±(0.8%+5) ±(0.8%+5)
AC voltage frequency (Hz) 10Hz~10kHz ±(1%+5) ±(1%+5) ±(1%+5)
10Hz~60kHz ±(0.5%+2) ±(0.5%+2)
DC voltage (V) 600V ±(0.5%+2) ±(0.5%+2) ±(0.5%+2) ±(0.5%+2) ±(0.5%+2)
Resistance (Ω) 40MΩ
60MΩ ±(0.8%+2) ±(0.8%+2)
Capacitance (F) 4mF ±(4%+5)
40mF ±(4%+5)
60mF ±(4%+5) ±(4%+5)
Temperature (℃) -40℃~1000℃ ±(1.5%+5) ±(1.5%+5)
Frequency (Hz) 10Hz~10MHz ±(1%+5) ±(0.1%+4) ±(0.1%+4)
Features
Display count 4000 4000 6000 4000 6000
Auto range √ √ √ √ √
Jaw opening 28mm 28mm 28mm 28mm 28mm
True RMS √ √ √ √ √
NCV √ √ √ √ √
Continuity test √ √ √ √ √
Diode √ √ √ √ √
MAX/MIN √ √ √ √ √
Relative mode √ √ √ √
Zero mode √ √
Data hold √ √ √ √ √
Low battery indication √ √ √ √ √
Auto power off √ √ √ √ √
General Characteristics
Power 1.5V battery (R03) x 2
Display 37mm x 25mm
Product color Red and grey
Product net weight UT201R/202R/202F: 248g; UT203R/204R: 235g
Product size 215mm x 63mm x 36mm
Standard accessories Batteries, test leads, Themocouple (UT202R/204R)
Standard individual packing Gift box, carrying bag, English manual
Standard quantity per carton 40pcs
Standard carton measurement 485mm x 295mm x 385mm
Standard carton gross weight UT201R: 16.6kg; UT202R: 17.1kg; UT203R: 16.1kg; UT202F/UT204R: 16.7kg
