Description
Rolls S6-460AGM-RE (L16) 6V 415Ah AGM VRLA Deep Cycle Battery
| Series | AGM-S | Warranty | See Warranty Terms |
|---|---|---|---|
| Volts | 6 | BCI | L16 |
| Cells | 3 | ||
| Terminal Type | F23-1 | ||
| Included Hardware | M10 stainless bolts & washers | ||
| Size & Thread | M10 | ||
| Charge | |
|---|---|
| Charge Voltage Range | 2.45 V/cell @ 25°C (77°F) |
| Float Voltage Range | 2.3 V/cell @ 25°C (77°F) |
| Recommended Charge Current | 85 A |
| Maximum Charge Current | 125 A |
| Self-Discharge Rate | Less than 2% per month at 25°C (77°F) |
| Internal Resistance | 1.6 mΩ |
| Capacity | |
|---|---|
| Cold Crank Amps (CCA) 0°F / -18°C | 1500 |
| Marine Crank Amps (MCA) 32°F / 0°C | 1800 |
| Reserve Capacity (RC @ 25A) | 885 Minutes |
| Reserve Capacity (RC @ 75A) | 229 Minutes |
| Capacity Affect by Temperature | 40°C (104°F) | 25°C (77°F) | 0°C (32°F) | -15°C (5°F) |
|---|---|---|---|---|
| 102% | 100% | 85% | 65% |
| Hour Rate | Capacity / AMP Hour | Current / AMPs |
|---|---|---|
| @ 100 Hour Rate | 460 AH | 4.6 A |
| @ 20 Hour Rate | 415 AH | 20.75 A |
| @ 10 Hour Rate | 374 AH | 37.4 A |
| @ 5 Hour Rate | 340 AH | 68 A |
| Cut Off Voltage | Constant Current Discharge | |||||
|---|---|---|---|---|---|---|
| 1.75 VPC | 1 hr | 2 hr | 3 hr | 5 hr | 8 hr | 10 hr |
| 232 | 123 | 93.9 | 68 | 45 | 37.4 | |
| Specifications | |||
|---|---|---|---|
 | Weight | 57 kg | 126 lbs |
| Length | 29.5 cm | 11.61“ | |
| Width | 18.0 cm | 7.09“ | |
| Height Inc. Term. | 42.3 cm | 16.65“ | |
| Product measurements & weights are calculated based on sample data. Individual specifications are subject to vary due to the manufacturing process & battery components. | |||
| Container | ABS | ||
|---|---|---|---|
| Cover | ABS | ||
| Handles | Rope / Plastic Handle | ||
Cycle Life vs. Depth of Discharge
Capacity vs. Temperature
Detailed Illustration
