Rolls S2 L16-SC 2V 1503Ah Flooded Deep Cycle Battery

Name: Rolls S2 L16-SC 2V 1503Ah Flooded Deep Cycle Battery - Canadian Battery Store
SKU: S2 L16-SC
Price: 628.50 CAD
Availability: InStock

SKU: S2 L16-SC

In Stock! Usually ships in 24 to 48 hours.

Est. Arrival Oct 5 - Oct 6

Pickup available at Saint-Jean-sur-Richelieu Warehouse-Québec J2W 2H1

Usually ready in 4 hours

Original price was: $897.86.Current price is: $628.50.

+ $20.00 Core Charge? What is a core charge? A refundable deposit for recycling old parts. Charge is refunded when you return your old part.

Add to wishlistAdd to compare

GTIN: 772748014388 Category: Solar Batteries

Product information

Weight	70.56 lbs
Dimensions	12.91 × 6.89 × 9.33 in
Application	Deep Cycle
Battery Type	Flooded Deep Cycle
Brand	Rolls
Capacity (Ah)	1503
Chemistry	Flooded
Cold Cranking Amps (CCA)	3378
Features	Heavy Duty
Group Size	L16
MCA	4223
Part No	S2 L16-SC
Reserve Capacity (RC)	2909 min
Terminal Type	LT
Voltage	2
Warranty	3 years

Description

Series	FLA SERIES 4000	Warranty	3 Years
Volts	2	Design	L16
Cells	1	Plates/Cell	53
Terminal Type		LT
Included Hardware		S/S Hex Cap Screw, Nut, Lock & Flat Washer
Size & Thread		5/16″-18
Cables		Optional: 19″ 4/0 interconnect cable

Charge \| Discharge
Charge Voltage Range	2.45-2.5 V/cell @ 25°C (77°F)
Float Voltage Range	2.25 V/cell @ 25°C (77°F)
Recommended Charge Current	175 A
Maximum Charge Current	290 A
Self-Discharge Rate	5%-10% per month at 25°C (77°F)

Capacity
Cold Crank Amps (CCA) 0°F / -18°C	3378
Marine Crank Amps (MCA) 32°F / 0°C	4223
Reserve Capacity (RC @ 25A)	2909 Minutes
Reserve Capacity (RC @ 75A)	764 Minutes

Capacity Affect by Temperature	40°C (104°F)	25°C (77°F)	0°C (32°F)	-15°C (5°F)
Capacity Affect by Temperature	105%	100%	75%	50%

Hour Rate	Capacity / AMP Hour	Current / AMPs
@ 100 Hour Rate	1728 AH	17.28 A
@ 72 Hour Rate	1683 AH	23.38 A
@ 50 Hour Rate	1623 AH	32.46 A
@ 20 Hour Rate	1503 AH	75.15 A
@ 15 Hour Rate	1413 AH	94.19 A
@ 10 Hour Rate	1353 AH	135.27 A
@ 8 Hour Rate	1293 AH	161.57 A
@ 5 Hour Rate	1202 AH	240.48 A
@ 1 Hour Rate	706 AH	706.41 A

Specifications
Weight	59 kg	130 lbs
Length	318 mm	12.5“
Width	181 mm	7.13“
Height Incl. Term.	432 mm	17“
Product measurements & weights are calculated based on sample data. Individual specifications are subject to vary due to the manufacturing process & battery components.

Electrolyte Reserve	57 mm	2.25“
Container	High Density Polypropylene
Cover	High Density Polypropylene
Handles	Rope / Plastic Handle
Plastics are UL94 HB (UL94-V2 available) Plastics are impact copolymer rated to ASTM D256, D5420 Vented design with integral flame arrestor vent caps

Cycle Life vs. Depth of Discharge

4000 IEC

Voltage vs. Depth of Discharge

voltage vs depth of discharge 4000

Detailed Illustration

S2 L16 Flooded spec footer
