Fast Charging
RELiON lithium batteries charge much faster than traditional lead-acid batteries, and they’re packed with more usable energy and up to 10 times longer life so you’re always ready to go!
Maintenance Free
Plug, play, and charge. No watering, no corrosion.
Constant Power
Full power available throughout discharge. Voltage does not drop like lead-acid.
Eco-Friendly & Safe
RELiON lithium batteries are the ultimate clean energy. No gassing, no fumes, and no pollution. Enjoy reliable power, while protecting the environment, using these non-hazardous batteries.
Built-In Protection
Every RELiON lithium battery comes with a state-of-the-art battery management system (BMS) that provides protection from over-charge, over-discharge and short circuit conditions. Battery cells are enclosed in explosion-proof stainless steel casings. Built-in thermal fuses and other safety features offer added protection.
Temperature Tolerant
Lithium batteries can handle a wide variety of conditions and are even 2.5x more efficient at low temperatures than lead-acid while being able to safely operate up to 149°F (65°C).
Lightweight
RELiON lithium batteries provide more power than lead-acid batteries and are typically half the weight. Boosting both performance and agility on the water.
Electrical Specifications | |
|---|---|
| Nominal Voltage | 25.6 V |
| Nominal Capacity | 100 Ah |
| Capacity @ 25A | 240 min |
| Energy | 2560 Wh |
| Resistance | ≤30 mΩ @ 50% SOC |
| Efficiency | 99% |
| Self Discharge | <3% per Month |
| Maximum Modules in Series | 1 (Single Use) |
Mechanical Specifications | |
|---|---|
| Dimensions (L x W x H) | 20.6 x 10.5 x 8.7” (522 x 267 x 220 mm) |
| Weight | 61.1 lbs (27.7 kg) |
| Terminal Type | M8 x 1.25 |
| Terminal Torque | 80 – 100 in-lbs (9 – 11 N-m) |
| Case Material | ABS |
| Enclosure Protection | IP67 |
| Cell Type – Chemistry | Cylindrical – LiFePO4 |
Discharge Specifications | |
|---|---|
| Maximum Continuous Discharge Current | 100 A |
| Peak Discharge Current | 200 A (7.5 s ±2.5 s) |
| BMS Discharge Current Cut-Off | 280 A ±50 A (9 ±4 ms) |
| Recommended Low Voltage Disconnect | 22 V |
| BMS Discharge Voltage Cut-Off | 16 V (2.0 ±0.08 vpc) (20 ±6 ms) |
| Reconnect Voltage | 20 V (2.5 ±0.05 vpc) |
| Short Circuit Protection | 200-600 µs |
Charge Specifications | |
|---|---|
| Recommended Charge Current | 5 A – 50 A |
| Maximum Charge Current | 100 A |
| Charge Current 32ºF to 14ºF (0 to -10 ºC) | ≤0.1 C |
| Charge Current -4ºF to 14ºF (-20 to -10 ºC) | ≤0.05 C |
| Recommended Charge Voltage | 28.4 V – 29.2 V |
| BMS Charge Voltage Cut-Off | 31.2 V (3.9 ±0.025 vpc) |
| (1.1 ±0.4 s) | |
| Reconnect Voltage | 28.8 V (3.8 ±0.05 vpc) |
| Balancing Voltage | 28.8 V (3.6 vpc) |
Temperature Specifications | |
|---|---|
| Discharge Temperature | -4 to 140 ºF (-20 to 60 ºC) |
| Charge Temperature* | -4 to 113 ºF (-20 to 45 ºC) |
| Storage Temperature | 23 to 95 ºF (-5 to 35 ºC) |
| BMS High Temperature Cut-Off | 176 ºF (80 ºC) |
| Reconnect Temperature | 122 ºF (50 ºC) |
| *Refer to charge currents below 0°C (32°F) | |
Compliance Specifications | |
|---|---|
| Certifications | UN38.3 & CE (battery) |
| UL1642 (File# MH64523) | |
| IEC62133 (cells) | |
| Shipping Classification | UN 3480, CLASS 9 |
TYPICAL LITHIUM IRON PHOSPHATE CHARACTERISTICS
