RELION RB300 LITH12-300 12V 300Ah LiFePO4 Deep Cycle Lithium Battery – Group 8D

Original price was: $7,842.00.Current price is: $4,705.20.

In stock
Buy it now
Brands:
SKU: RB300
ELECTRICAL SPECIFICATIONSMECHANICAL SPECIFICATIONS
Nominal Voltage12.8 VDimensions (L x W x H)20.5 x 10.5 x 9.0” 520 x 267 x 228 mm
Nominal Capacity300 AhWeight75.8 lbs (34.36 kg)
Capacity @ 25A720 minTerminal TypeM8 x 1.25
Energy3840 WhTerminal Torque80 – 100 in-lbs (9 – 11 N-m)
Resistance≤30 mΩ @ 50% SOCCase MaterialABS
Efficiency99%Enclosure ProtectionIP66
Self Discharge<3% per MonthCell Type – ChemistryCylindrical – LiFePO4
Maximum Modules in Series6



DISCHARGE SPECIFICATIONSCHARGE SPECIFICATIONS
Maximum Continuous Discharge Current100 ARecommended Charge Current15 A – 50 A
Peak Discharge Current200 A (7.5 s ±2.5 s)Maximum Charge Current100 A
BMS Discharge Current Cut-Off280 A ±50 A (9 ±4 ms)Charge Current 32ºF to 14ºF (0 to -10 ºC)≤0.1 C
Recommended Low Voltage Disconnect11 VCharge Current -4ºF to 14ºF (-20 to -10 ºC)≤0.05 C
BMS Discharge Voltage Cut-Off8 V (2.0 ±0.08 vpc) (140 ±60 ms)Recommended Charge Voltage14.2 V – 14.6 V
Reconnect Voltage9.2 V (2.3 ±0.1 vpc)BMS Charge Voltage Cut-Off15.6 V (3.9 ±0.025 vpc)
Short Circuit Protection200-600 µs (1.1 ±0.4 s)
  Reconnect Voltage15.2 V (3.8 ±0.05 vpc)
  Balancing Voltage14.4 V (3.6 ±0.025 vpc)



TEMPERATURE SPECIFICATIONSCOMPLIANCE SPECIFICATIONS
Discharge Temperature-4 to 140 ºF (-20 to 60 ºC)CertificationsCE (battery)
Charge Temperature*-4 to 113 ºF (-20 to 45 ºC) UN38.3 (battery)
Storage Temperature23 to 95 ºF (-5 to 35 ºC) UL1642 & IEC62133 (cells)
BMS High Temperature Cut-Off176 ºF (80 ºC)Shipping ClassificationUN 3480, CLASS 9
Reconnect Temperature122 ºF (50 ºC)
*Refer to charge currents below 0°C (32°F)
Weight82.69 lbs
Dimensions20.47 × 10.51 × 8.98 in
