Cold Weather Ready
With a robust system that draws power from the charger itself, LT models do not require additional components – such as a heated blanket – to bring the battery to a safe temperature for charging.
Lightweight
RELiON lithium batteries provide more power than lead-acid batteries and are typically half the weight. Boosting both performance and agility on the water.
Constant Power
Full power is available throughout discharge. Voltage does not drop like lead-acid.
Eco-Friendly & Safe
RELiON lithium batteries are the ultimate clean energy. No gassing, no fumes, and no pollution. Enjoy reliable power, while protecting the environment, using these non-hazardous batteries.
Maintenance Free
Plug, play, and charge. No watering, no corrosion.
ELECTRICAL SPECIFICATIONS | |
|---|---|
| Nominal Voltage | 12.8 V |
| Nominal Capacity | 100 Ah |
| Capacity @ 25 A | 240 min |
| Energy | 1280 Wh |
| Resistance | ≤30 mΩ @ 50% SOC |
| Efficiency | 99% |
| Self Discharge | <3% per Month |
| Maximum Batteries Connected in Series | 1 (Single-Use) |
MECHANICAL SPECIFICATIONS | |
|---|---|
| Dimensions (L x W x H) | 13 x 6.8 x 8.4” (329 x 172 x 214 mm) |
| Weight | 27.9 lbs (12.64 kg) |
| Terminal Type | M8 x 1.25 |
| Terminal Torque | 80 – 100 in-lbs (9 – 11 N-m) |
| Case Material | ABS |
| Enclosure Protection | IP67 |
| Cell Type – Chemistry | Cylindrical – LiFePO4 |
DISCHARGE SPECIFICATIONS | |
|---|---|
| Maximum Continuous Discharge Current | 100 A |
| Peak Discharge Current | 200 A (7.5 s ±2.5 s) |
| Discharge Over-Current Protection | 280 A ±50 A (32 ±10 ms) |
| Recommended Low Voltage Disconnect | 11.0 V |
| Discharge Under-Voltage Protection | 9.2 V (2.3 ±0.08 vpc) (4.7 ±1 s) |
| Reconnect Voltage | 10.0 V (2.5 ±0.1 vpc) |
| Short Circuit Protection Response Time | 200-600 μs |
CHARGE SPECIFICATIONS | |
|---|---|
| Recommended Charge Current | 5 A – 50 A |
| Maximum Continuous Charge Current | 100 A |
| Recommended Charge Voltage | 14.2 V – 14.6 V |
| BMS Charge Voltage Cut-Off | 15.4 V (3.85 ±0.025 vpc) (1000 ±200 ms) |
| Reconnect Voltage | 14.6 V (3.65 ±0.05 vpc) |
| Balancing Voltage | 14.4 V (3.6 ±0.025 vpc) |
TEMPERATURE SPECIFICATIONS | |
|---|---|
| Discharge Temperature | -4 to 140 ºF (-20 to 60 ºC) |
| Charge Temperature | -4 to 113 ºF (-20 to 45 ºC) |
| Recommended Storage Temperature | 23 to 95 ºF (-5 to 35 ºC) |
| BMS High Temperature Cut-Off – Discharge | 185 ºF (85 ºC) |
| BMS High Temperature Cut-Off – Charge | 140 ºF (60 ºC) |
| Reconnect Temperature | 122 ºF (50 ºC) |
HEATING ELEMENT SPECIFICATIONS | |
|---|---|
| Heating Temperature Range | -4 to 41 ºF (-20 to 5 ºC) |
| Heating Time | Approximately 1 hr @ 10 A |
COMPLIANCE SPECIFICATIONS | |
|---|---|
| Certifications | UN38.3 (battery) & CE (battery) UKCA |
| UL1642 (cells) (File# MH64523) | |
| IEC62133 (cells) | |
| Shipping Classification | UN 3480, CLASS 9 |
TYPICAL LITHIUM IRON PHOSPHATE CHARACTERISTICS
