RELION RB100 LITH12-100 12V 100Ah LiFePO4 Deep Cycle Lithium Battery – Group 31

Original price was: $2,722.40.Current price is: $1,633.43.

In stock
Buy it now
Brands:
SKU: RB100
ELECTRICAL SPECIFICATIONS MECHANICAL SPECIFICATIONS
Nominal Voltage 12.8 V Dimensions (L x W x H) 12.95 x 6.77 x 8.9” 329 x 172 x 223 mm
Nominal Capacity 100 Ah Weight 27.9 lbs (12.64 kg)
Capacity @ 25A 240 min Terminal Type M8 x 1.25
Energy 1280 Wh Terminal Torque 80 – 100 in-lbs (9 – 11 N-m)
Resistance ≤30 mΩ @ 50% SOC Case Material ABS
Efficiency 99% Enclosure Protection IP66
Self Discharge <3% per Month Cell Type – Chemistry Cylindrical – LiFePO4
Maximum Modules in Series 1 (Single-Use)



DISCHARGE SPECIFICATIONS CHARGE SPECIFICATIONS
Maximum Continuous Discharge Current 100 A Recommended Charge Current 5 A – 50 A
Peak Discharge Current 200 A (7.5 s ±2.5 s) Maximum Charge Current 100 A
BMS Discharge Current Cut-Off 280 A ±50 A (32 ±10 ms) Recommended Charge Voltage 14.2 V – 14.6 V
Recommended Low Voltage Disconnect 11 V BMS Charge Voltage Cut-Off 15.4 V (3.85 ±0.025 vpc) (1000 ±200 ms)
BMS Discharge Voltage Cut-Off 9.2 V (2.3 ±0.08 vpc) (4.7 ±1 s) Reconnect Voltage 14.6 V (3.65 ±0.05 vpc)
Reconnect Voltage 10 V (2.5 ±0.1 vpc) Balancing Voltage 14.4 V (3.6 ±0.025 vpc)
Short Circuit Protection 200-600 μs Recommended Charge Current 5 A – 50 A
    Maximum Charge Current 100 A



TEMPERATURE SPECIFICATIONS HEATING ELEMENT SPECIFICATIONS
Discharge Temperature -4 to 140 ºF (-20 to 60 ºC) Heating Temperature Range -4 to 41 ºF (-20 to 5 ºC)
Charge Temperature -4 to 113 ºF (-20 to 45 ºC) Heating Time Approximately 1 hr @ 10 A
Storage Temperature 23 to 95 ºF (-5 to 35 ºC)
BMS High Temperature Cut-Off – Discharge 185 ºF (85 ºC)
BMS High Temperature Cut-Off – Charge 140 ºF (60 ºC)
Reconnect Temperature 122 ºF (50 ºC)



COMPLAINCE SPECIFICATIONS
Certifications CE (battery)
  UL1642 & IEC62133 (cells)
Shipping Classification UN 3480, CLASS 9
Weight 29.77 lbs
Dimensions 12.95 × 6.77 × 8.78 in
