FUNCTIONAL SPECIFICATIONS | |
---|---|
Nominal Voltage | 12.8V |
Cell Chemistry | LiFePO4 |
Cell Type | Prismatic |
Ampere-hour Capacity | 120Ah |
Watthour Capacity | 1536Wh |
Specific Energy | 128Wh/kg |
Impedance (50% SOC, 1kHz) | <100mΩ |
Cycles @ 80% DOD | >3500 |
Parallel Capable | Yes (up to 10) |
Series Capable | No |
MECHANICAL SPECIFICATIONS | |
---|---|
BCI Size | GC2 / GC8 |
Dimensions (LxDxH) | 260x180x276mm (10.2 x 7.1 x 10.9 in) |
Weight | 15.6 kg (34.4 lbs) |
Case Material | ABS |
Stud / Insert Terminal | M8 X 1.25 – 20 |
Ingress Protection Marking | IP67 |
Case Flame Rating | UL94 V-0 |
DISCHARGE SPECIFICATIONS | |
---|---|
Recommended Continuous Discharge Current | 120A (1C) |
Maximum Continuous Discharge Current | 200A |
Peak Over Current | 200A<lbatt<300A, 10s300A<lbatt<360A, 5s360A<lbatt<500A, 2sIbatt>500A, 0.5s |
Short-Circuit Protection | >500A |
Short-Circuit Reset | Automatic |
Discharge Cut Off Pulse Recovery Operation | Automatically above 2.9V/cell (11.6V) |
Low Voltage Protection | 2.8V/cell (11.2V)~6 months @ 25°C (60°F) |
Permanent Off  Voltage | 1.8V/cell (7.2V) |
CHARGE SPECIFICATIONS | |
---|---|
Recommended Charging Current | 60A (0.5C) |
Continuous Charge Current |  120A (1C) |
Disconnect Charge Current | lbatt>120A, 5sIbatt>200A, 0.5s |
Peak Charge Voltage | 14.3V |
Float Voltage | 13.5V |
Over-Voltage Protection | 3.65V/cell 4s (14.6V) |
Over-Voltage Reset | Automatically at 3.6V/cell (14.4V) |
ENVIRONMENTAL SPECIFICATIONS | |
---|---|
Charge Under Temperature | 0°C (32°F) for 2s. Self-reset function. |
Charge Over Temperature | 55°C (131°F) for 2s. Self-reset function. |
Discharge Under Temperature | -20°C (-4°F) for 2s. Self-reset function. |
Discharge Over Temperature | 55°C (131°F) for 2s. Self-reset function. |
Operating Humidity Range | 10% to 95% RH non-condensing |
Optimal Storage Temperature | 10°C to 35°C (50°F to 95°F) |
Optimal Storage Humidity | 15% to 90% RH |
CERTIFICATIONS | |
---|---|
UL1973 pending (Battery Pack) | |
CE (Battery Pack) | |
IEC 62133-2 :2017 (Lithium Batteries) |
