Description
Specification Details
| Parts per Unit | 1, 50 |
|---|---|
| Features | Convenient for field service work near battery not under engine, Copper conductor for maximum conductivity, Cuts inventory by reducing stock of slow moving longer cables, permits proper fitting repair parts to be available anytime, Ideal for mobile repair vans, tow trucks and other service vehicles, Restore your original starting power, Temperature range: 221°F (105°C) to -58°F (-50°C) |
| Application | Mobile Repair Vans, Tow Trucks |
| Gauge | 12, 4 |
| Connection Type | Clamp to Tie Bolt, Clamp to Tie Bolt to Butt Connector |
| Cable Nominal Outer Diameter | |
| Insulation Material | PVC |
| Insulation Thickness | 0.06 in |
| Pack Type | Bag, Box |
| Polarity | Universal |
| Prop 65 Item | DEHP, DINP, Lead |
| Strand Count | 70 |
| Stud Hole Size | 3/8 in |
| Subject to Prop 65 | Yes |
| Temperature Range (°C) | -50 to 105°C |
| Temperature Range (°F) | -58 to 221°F |
| Termination Material | Lead |
| Thimble | No |
| UL / CSA | No |
| Brand | Not branded |
| Cable Nominal Outer Diameter | 0.28 in |
| Color | Black, Red |
| Product Length | 6.87 in |
| RoHS Compliant | Yes |
| Works With | Side Posts, Top Post |
| SKU | 9603-050U, 9603-2001U, 9603U |
| Assembly Cable Length | 6.87 in |
| Product Weight | 0.77 lb |
| Tristrip Statement | Strip .91″ (23 mm) minimum of insulation from end, fully insert in connector & crimp at two locations. |
| Tristrip Statement / Spanish | Strip 0.91 ” ( 23 mm ) como mínimo de aislamiento del extremo , totalmente insertar en el conector y engarzado en dos lugares. Bande de 0,91 ” ( 23 mm ) |
| UL Statement | QuickCable UL Listed connectors are for use on stranded copper wire only. |
| Country of Origin | USA |
