Power Probe 3Ez W/ Case & Acc -Red

Features & Benefits

• Power Probe PP3EZREDAS Power Probe 3EZ with Case & Accessories – Red
• Easy Learning – Teaches a new user how to use the functions in the tool.
• Easy Diagnostics – Guides a user through simple tests such as Battery Testing, Charging System Testing, Fuse Testing, and Voltage Checks. Simply scan the QR Code with your Smart Device, which will link to a video to guide the user to perform these tests.
• The easy to read LCD display – Provides easy to see readings with a simple navigation menu to get to what you need fast.
• Upside Down? No Problem! With a new flip screen feature, you can see screen readings while holding the tool upside down.
• Safety First. The 8 amp thermal circuit breaker provides protection while powering up components, relays or circuits while still allowing inrush current for larger draw components.
• It’s Menu Driven. The PP3EZ has a menu driven screen that makes navigating a breeze for easier diagnosing of electrical issues.
• This is an essential electrical tool. The PP3EZ is an all-in-one tool with DC Voltmeter, MIN, MAX, and Peak to Peak mode, along with audio signal capability (AC Threshold).
• Storage temperature/humidity: -20 to 70 °C, 70% RH max
• Operating temperature/humidity: -10 to 50 °C, 70%RH max
• Pollution degree:2
• Voltage & Polarity testing
• Continuity testing
• Activating components out of the vehicle’s electrical system
• Activating electrical components in the Vehicle
• Activating electrical components with ground
• Testing trailer lights and connections
• Checking for bad ground contacts
• Red/Green Indicator & Audio Tone
• DC 0 to +70V +1 Digit
• P-P 0 to +70V
• The frequency response for tone pass through

10Hz to 10kHz

• PP Display

15 Hz Square Wave

35 Hz Sine Wave

• Power Probe Mode – Continuity to ground

First level – Display is enabled less than 20 K Ω

Second level – Green LED is enabled less than approx. 600 Ω

– & +Peak Detector Response

• Single event capture less than 200ms pulse width
• Repetitive events less than 1ms pulse width
• Peak to Peak Mode

0 to + 70 + 1 Digit

4Hz to over 500kHz Square Wave input

4Hz to over 250kHz Sine Wave input

The threshold for PPAC/Audible passthrough

OverVolt Warning!!

If the probe tip connects to a voltage greater than +70 Volts the display will show an “Over Volt” warning. Remove the probe tip immediately to prevent internal damage to the tool.

Over Load Warning

If the probe is connected to a battery with a voltage greater than 34 VDC the display will show an “Over Load” warning.

Circuit Breaker

8 amp thermal response – Manual reset

• Typical Response
• 8 amps 10amps 15amps 25amps Short Circuit
• No Trip 20min 6 sec. 2 sec. 0.3 sec.

• The PP3EZAS Kit includes:

Power Probe 3EZ

Optional 20ft Extension Lead (with AS Kit) for a total of 40ft. (Perfect for working on large trucks or trailers)

Optional Cigarette Lighter Adapter (with AS Kit)

Battery Clip-Set (for connecting to vehicle battery)

Convenient Carrying Case
