Features & Benefits
- Heavy duty hydraulic service for garages, equipment dealers, commercial service and more.
- Welded hydraulic pump and cylinder construction provides increased strength and leak protection
- Chrome plated ram for additional rust resistance
- Wiper seals protect hydraulic system from contaminants
- Front wheels with roller bearings and ball bearing-mounted rear caster wheels provide stability and easy maneuvering
- Overload and bypass safety valves prevent use beyond rated capacity ad over extension of the ram
- Handle can be locked in three positions from horizontal to vertical and has independent release knob
- Uses shop air supply for lifting assistance
- OTC Owners Manual for service jacks with training (operating) instructions
- Capacity | 10 Ton lifting capacity
- Air pressure | 80 – 120 PSI
- Lifting | 6-3/8″ to 22″
- Reach | 106.2″
- Saddle | 6″ dia., round
- Frame Height | 9.8″
- Handle length | 45.4″ 3-position with lock and release controls
- Floor space| 18.9″ x 60.8″
- Casters | 4; 5.6″ fixed front (2), 3.6″ mid-body swivel (2)
