Jet AL100-200-20 2-Ton Hand Chain Hoist w/ 20′ Lift (133220)

The Jet AL100-200-20 2-Ton Hand Chain Hoist w/ 20′ Lift (133220) is a reliable and efficient 2-ton hand chain hoist designed to simplify the lifting of heavy materials. Built with durability in mind, this hoist is perfect for various applications, from workshops to construction sites.

KEY FEATURES AND BENEFITS:

• Effortless Lifting: The extra-large hand chain opening allows for easy and comfortable operation, reducing strain on the user.
• Weather Resistance: The sealed housing protects internal components from moisture, dust, and other environmental factors, ensuring long-lasting performance.
• Safety First: Equipped with cast steel safety latches and a dual pawl Weston style brake, the hoist prioritizes user safety.
• Durable Construction: Made from high-quality cast steel and featuring a heat-treated Grade 100 load chain, the Jet 133220 is built to withstand demanding work environments.
• Compact Design: With a smaller headroom compared to traditional chain hoists, this model offers greater flexibility in confined spaces.

SPECIFICATIONS:

• Load Capacity: 2 tons (4400 lbs)
• Lift: 20 feet
• Hand Chain Pull to Lift 1 foot: 71 lbs
• Headroom: 15-3/8 inches
• Load Chain Dimension: 8 x 24 mm
• Net Weight: 47.86 lbs
• Number of Fall: 1
• Compliance: ANSI/ASME B30.16 and HAST-2 Standards

HOW TO USE:

1. Inspect the hoist: Before each use, check for any signs of damage or wear.
2. Position the hoist: Securely attach the hoist to a suitable overhead support structure.
3. Attach the load: Connect the load chain to the lifting hook and ensure it is securely fastened.
4. Operate the hand chain: Pull down on the hand chain to lift the load.
5. Lower the load: Gently release the hand chain to lower the load.
6. Lock the brake: Engage the brake to securely hold the load in position.

BENEFITS OF USING JET AL100-200-20 2-TON HAND CHAIN HOIST W/ 20′ LIFT (133220):

• Increased productivity through efficient lifting
• Reduced risk of injuries from manual handling
• Improved safety with reliable braking and safety features
• Durable construction for long-term use
• Versatile for various lifting applications

FEATURES:

• Extra-large hand chain opening
• Sealed housing for weather resistance
• Cast steel safety latches
• Dual pawl Weston style brake
• Grade 100 load chain
• Patented fused brake design (lifetime warranty)
• Compact design with smaller headroom
