Electrical Specifications
| Nominal Voltage | 12V |
|---|---|
| C100 | 61 Ah |
| C20 | 55 Ah |
| C10 | 46 Ah |
| C5 | 44 Ah |
| C3 | 38 Ah |
| C2 | 33 Ah |
| C1 | 31 Ah |
| CCA | 350 Amps |
| CA or MCA | 450 Amps |
| PHCA | 825 Amps |
| Internal Resistance | 9.0 mΩ |
Mechanical Specifications
| Group Size | 22NF |
|---|---|
| Terminal Type | M6 |
| Terminal Torque | 3.3 – 4.8 / 40 – 57.5 / 4.5 – 6.5 |
| Height (w/ terminal) | 8.35 in / 212 mm |
| Height (case only) | 8.19 in / 208 mm |
| Width | 5.43 in / 138 mm |
| Length | 9.02 in / 229 mm |
| Weight | 36.2 lbs / 16.4 kg |
| Case Type | ABS Plastic |
