Electrical Specifications
| Nominal Voltage | 12V |
|---|---|
| C100 | 38 Ah |
| C20 | 35 Ah |
| C10 | 32 Ah |
| C5 | 29 Ah |
| C3 | 24 Ah |
| C2 | 23 Ah |
| C1 | 22 Ah |
| CCA | 225 Amps |
| CA / MCA | 275 Amps |
| PHCA | 450 Amps |
| Internal Resistance | 9.0 mΩ |
Mechanical Specifications
| Group Size | U1 |
|---|---|
| Terminal Type | M6 |
| Terminal Torque | 3.3 – 4.8 / 40 – 57.5 / 4.5 – 6.5 |
| Height (with terminal) | 6.57 in / 167 mm |
| Height (case only) | 6.1 in / 155 mm |
| Width | 5.16 in / 131 mm |
| Length | 7.72 in / 196 mm |
| Weight | 21.8 lbs / 9.9 kg |
| Case Type | ABS Plastic |
