Fluke A3002 FC Wireless AC/DC Current Module

Fluke a3002 FC Wireless AC/DC Current Module
Fluke Connect enabled AC/DC Current Module

The Fluke a3002 FC current module wirelessly relays measurements from a current clamp accessory to Fluke Connect enabled master units. The a3002 FC was designed to be used with the i410 or i1010 AC/DC current clamps (not included).

Capable of measuring up to 400A AC/DC when used with the i410 current clamp, and either 600A AC or 1000A DC when combined with the i1010 current clamp. Internal logging feature allows for up to 65,000 readings to be stored. The a3002 FC can be utilized as a standalone unit or combined with other Fluke Connect modules, allowing you to completely customize your wireless test tool suite.Fluke a3002 FC Wireless AC/DC Current Module
Fluke Connect enabled AC/DC Current Module

The Fluke a3002 FC current module wirelessly relays measurements from a current clamp accessory to Fluke Connect enabled master units. The a3002 FC was designed to be used with the i410 or i1010 AC/DC current clamps (not included).

Capable of measuring up to 400A AC/DC when used with the i410 current clamp, and either 600A AC or 1000A DC when combined with the i1010 current clamp. Internal logging feature allows for up to 65,000 readings to be stored. The a3002 FC can be utilized as a standalone unit or combined with other Fluke Connect modules, allowing you to completely customize your wireless test tool suite.

Fluke A3002-FC Specifications

Function
Range
Resolution
Accuracy1

A dc
1000 A
0.1 A
(0.5 % + 3)

A ac
600.0 A
0.1 A
(1.0 % + 3)

1AC accuracy is specified from 45 Hz to 1000 Hz

Maximum voltage between terminal and earth ground (module)
30 V dc or ac rms

LCD w/backlight
3.5 digits, 6000 counts, 4/sec update rate

Log rate/Interval
Adjustable by PC from 1 sec to 1 hr, default 1 min

Battery type
2 AA Alkaline batteries, NEDA 15A, IEC LR6

Battery life
400 hours minimum

Memory
Record up to 65,000 readings

RF communications
2.4 GHz ISM Band

RF communication range
Open air, unobstructed: Up to 20 m

Obstructed, sheetrock wall: Up to 6.5 m

Obstructed, concrete wall or steel electrical enclosure: Up to 3.5 m

Operating temperature
-10 °C to +50 °C

Storage temperature
-40 °C to +60 °C

Temperature coefficient
0.1 X (specified accuracy)/°C (< 18 °C or > 28 °C)

Relative humidity
0 % to 90 % (0 °C to 35 °C), 0 % to 75 % (35 °C to 40 °C),
0 % to 45 % (40 °C to 50 °C)

EMC
IEC 61236-1, Portable

Safety compliance
Protected to IEC 61010-1, 600 V CAT IV / 1000 V CAT III, 3rd edition
Pollution Degree 2

Certifications
CSA, CE, FCC: T68-FBLE IC: 6627A-FBLE

Ingress Protection (IP) rating
IP42

Size (HxWxD)
160 mm x 66 mm x 38 mm (6.3 in x 2.6 in x 1.5 in)

Weight
0.255 kg (9 oz)

Click here for complete specifications on the Fluke A3002FC

What’s included with the Fluke A3002FC
Fluke A3002 FC Wireless AC/DC Current Module

See it. Save it. Share it. All the facts, right in the field.

Fluke engineers have delivered an innovative mobile platform and tool that helps solve everyday problems, allowing you to instantly document measurements, retrieve historical data, and share live measurements with your team. All handled by the Android™ or iOS smart phone you already carry.

Fluke Connect with ShareLive™ video call is the only wireless measurement system that lets you stay in contact with your entire team without leaving the field. The Fluke Connect mobile app is works with over 20 different Fluke products – the largest suite of connected test tools in the world.

Make the best decisions faster than ever before by viewing temperature, mechanical, electrical and vibration measurements for each equipment asset in one place. Get started saving time and increasing your productivity.

Fluke Connect Features:

TrendIt™ Graphs: Use graphing to show changes in measurements, allowing you to graph and show problems instantly.

EquipmentLog™ History: Access equipment history building a database of equipment health and baselines with cloud backup.

ShareLive™ Video Calls: Save, collaborate and share measurements instantly with your team anytime, from anywhere.

AutoRecord™ Measurements: Instantly save measurements to your phone with Cloud backup.

Fluke Cloud™ Storage: Securely access equipment records anywhere, anytime.

Fluke Connect Benefits:

Maximize uptime

Minimize maintenance costs

Better assessments with accurate records

Higher efficiency with less walking around; no notebook and excel needed

Share troubleshooting knowledge live

Create and share helpful content in the field

Access to Fluke digital product manuals means no need to carry manuals in the field

Keep organized manually entered measurements
