| Specification |
| Cells Per Unit | 6 |
| Voltage Per Unit | 12 V |
| Capacity | 160Ah @ 10hr-rate to 1.80V per cell @ 25°C (77°F) |
| Weight | Approx. 54.8 Kg (120.78 lbs) |
| Maximum Discharge current | 800A (5sec) |
| Internal Resistance | Approx. 3.70 mΩ |
| Operating Temperature Range | Discharge：-15℃~50℃ (5°F~122°F) Charge：-15℃~40℃ (5°F~104°F) Storage：-15℃~40℃ (5°F~104°F) |
| Nominal Operating Temperature Range | 25℃±3℃ (77°F±5°F) |
| Float charging voltage | 13.5 ~ 13.8 VDC/Unit Average at 25℃ (77℉) |
| Recommended Maximum Charging current limit | 48A |
| Equalization and Cycle Service | 14.4 ~ 15.0 VDC/Unit at 25℃ (77℉) |
| Self Discharge | Less than 10% after 90 days, can be stored up to 6 months at 25℃ (77℉) |
| Terminal | I2 thread lead alloy terminal to accept M6 bolt |
| Container Material | Flame Retardant ABS (UL 94-V0) |
