Description
 |
| Specification |
| Cells Per Unit | 1 |
| Voltage Per Unit | 2 V |
| Capacity | 260Ah @ 10hr-rate to 1.80V per cell @25 ℃(77°F) |
| Weight | Approx. 18.7 Kg (41.21 lbs) |
| Maximum Discharge Current | 1560A (5sec) |
| Internal Resistance | Approx. 0.36 mΩ |
| Operating Temperature Range | Discharge：-20℃~50℃ (-4°F~122°F) Charge：0℃~40℃ (32°F~104°F) Storage：-20℃~40℃ (-4°F~104°F) |
| Nominal Operating Temperature Range | 25℃±3℃ (77°F±5°F) |
| Float Charging Voltage | 2.21 ~ 2.25 VDC/Unit Average at 25℃ (77℉) |
| Recommended Maximum Charging Current Limit | 78A |
| Equalization and Cycle Service | 2.35 VDC/Unit at 25℃ (77℉) |
| Self Discharge | Less than 10% after 90 days, can be stored up to 6 months at 25℃ (77℉) |
| Terminal | I4 thread copper alloy terminal to accept M8 bolt |
| Container Material | Flame Retardant ABS (UL 94-V0) |
 |
