Asus ROG Strix Z790-A GAMING WIFI Gaming Desktop Motherboard – Intel Z790 Chipset – Socket LGA-1700 – ATX
Core, Pentium Gold, Celeron Processor Supported – 128 GB DDR5 SDRAM Maximum RAM – DIMM, UDIMM – 4 x Memory Slots – Gigabit Ethernet – 2.5Gigabit Ethernet – IEEE 802.11 a/b/g/n/ac/ax – HDMI – DisplayPort – 4 x SATA Interfaces
Well-versed in style, performance, cooling, and connectivity, the DDR5 variant of the ROG Strix Z790-A exudes the same balance as its D4 brethren, but after taking a master class in memory. A robust VRM topped with stout silver heatsinks comfortably articulates power for the latest Intel? 13th Gen Core processors, while PCIe 5.0, WiFi 6E, and high-speed USB flesh out the board’s fluency across a variety of disciplines. And a vast collection of tuning options and utilities derived from its ROG heritage are the icing on top. PCIE? SLOT Q-RELEASE A physical button unlocks the first PCIe slot’s security latch with one press, greatly simplifying the process of detaching a PCIe card from the motherboard when it’s time to upgrade to a new GPU or other compatible device. ALL-ROUND PERFORMANCE Robust power delivery, breakneck DDR5 memory, speedy storage, and comprehensive cooling elevate any build with the ROG Strix Z790-A at its center. AI OVERCLOCKING Tuning is now faster and smarter than ever before. ASUS AI Overclocking profiles the CPU and cooling to predict the optimal configuration and push the system to its limits. Predicted values can be engaged automatically or used as a launching ground for further experimentation. LEADING CONNECTIVITY Next-gen connectivity and low-latency networking are hallmarks of the ROG ecosystem, and the Strix Z790-A delivers both of them in full. Joining them is an advanced audio solution for immersive sound so you can pick out the slightest cues and nuances. WIFI 6E Onboard WiFi 6E technology takes advantage of newly available spectrum in the 6 GHz band to provide up to seven 160 MHz channels for ultrafast throughput and better performance in dense wireless environments. 2.5G Ethernet Low-latency gaming, speedy file transfers, and high-resolution video streaming are among the many perks of onboard Intel? 2.5 Gbps Ethernet. PLAY IN STYLE Bold aesthetics and Aura Sync RGB controls let the ROG Strix Z790-A shine in every build. UNDENIABLY ROG STRIX The ROG Strix Z790-A boldly embraces the light, for an alternate take on build themes to its dark and brooding brother, the Strix Z790-F. Silver metallic heatsinks pop against a dark PCB backdrop and call attention to the board’s high capacity for thermal management. A transparent layer on the I/O shield adds a unique touch and emphasizes the customizable RGB logo below. The whole design is tied together with ROG-centric detailing on the board, heatsinks, and I/O shield for a vibrant and futuristic outlook. Pair the Strix Z790-A with other products from the diverse ROG ecosystem to create a fully-customized gaming setup that reflects your personal style. SOFTWARE UTILITIES A myriad of ROG-exclusive tools put advanced system tuning and configuration at your fingertips. AI COOLING II Balance the thermals and acoustics of any build with a single click. A proprietary ASUS algorithm slashes unnecessary noise while running a quick stress test, and then monitors CPU temperatures to dynamically adjust fans to optimal speeds.
Package Contents:
Strix Z790-A GAMING WIFI Gaming Desktop Motherboard 2 x SATA 6Gb/s cables 1 x Thermal pad for M.2 1 x ASUS Wi-Fi moving antennas 1 x Cable ties package 1 x M.2 backplate Q-Latch package 1 x M.2 Q-Latch package 1 x ROG key chain 1 x ROG Strix stickers 1 x ROG Strix thank you card 2 x M.2 Rubber Packages 1 x M.2 backplate Rubber 1 x User guide
General Information
Manufacturer:
ASUS Computer International
Manufacturer Part Number:
ROGSTRIXZ790AGAMINGW
Manufacturer Website Address:
http://www.asus.com
Brand Name:
Asus ROG
Product Line:
Strix
Product Model:
Z790-A GAMING WIFI
Product Name:
Strix Z790-A GAMING WIFI Gaming Desktop Motherboard
Marketing Information:
Product Type:
Gaming Desktop Motherboard
Processor & Chipset
Chipset Manufacturer:
Intel
Chipset Model:
Z790
Total Processor Supported:
1
Processor Socket:
Socket LGA-1700
Processor Generation Supported:
13th Gen12th Gen
Processor Supported:
CorePentium GoldCeleron
Memory
Number of Memory Slots:
4
Memory Form Factor:
DIMMUDIMM
Maximum Memory Supported:
128 GB
Memory Technology:
DDR5 SDRAM
Memory Speed Supported:
7800 MHz7000 MHz6800 MHz6600 MHz6400 MHz6200 MHz6000 MHz5800 MHz5600 MHz5400 MHz5200 MHz5000 MHz4800 MHz
I/O Controller
Controller Type:
Serial ATA/600
RAID Supported:
Yes
RAID Levels:
01510
Video
Onboard Video:
CPU Dependent Video
Audio
Audio Channels:
7.1
Network & Communication
Bluetooth:
Yes
Bluetooth Standard:
Bluetooth 5.3
Gigabit Ethernet:
Yes
2.5Gigabit Ethernet:
Yes
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11 a/b/g/n/ac/ax
I/O Expansions
Total Number of Expansion Slots:
4.0
PCI Express Standard:
PCI Express 5.0PCI Express 3.0PCI Express 4.0
Total Number of PCI Express Slots:
4
Number of PCI Express x1 Slots:
1
Number of PCI Express x16 Slots:
3
Interfaces/Ports
Total Number of USB Ports:
10
Number of USB 3.2 Gen 1 Type-A Ports:
4
Number of USB 3.2 Gen 2 Type-A Ports:
2
Number of USB 3.2 Gen 2 Type-C Ports:
1
S/PDIF:
Yes
HDMI:
Yes
HDMI Version:
2.1
DisplayPort:
Yes
Number of Network (RJ-45) Ports:
1
Thunderbolt:
Yes
Onboard Interfaces
Number of SATA Interfaces:
4
Number of M.2 Interfaces:
4
Total Number of Onboard USB Ports:
7
Number of Onboard USB 2.0 Ports:
4
Physical Characteristics
Form Factor:
ATX
Width:
12″ (304.80 mm)
Depth:
9.60″ (243.84 mm)
Miscellaneous
Package Contents:
Strix Z790-A GAMING WIFI Gaming Desktop Motherboard 2 x SATA 6Gb/s cables 1 x Thermal pad for M.2 1 x ASUS Wi-Fi moving antennas 1 x Cable ties package 1 x M.2 backplate Q-Latch package 1 x M.2 Q-Latch package 1 x ROG key chain 1 x ROG Strix stickers 1 x ROG Strix thank you card 2 x M.2 Rubber Packages 1 x M.2 backplate Rubber 1 x User guide
Brand Compatibility:
Intel
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
