ES Inc. #597 Dmm Including Ir Thermometer

Features & Benefits

• Highest Quality Auto-Ranging DMM Designed for Automotive Trouble Shooting
• 18 Test Functions, 48 Test Ranges
• Peak Min/Max records transient voltages as fast as 1 millisecond
• Min/Max Mode records variations in all functions
• Exclusive Non-Contact IR Thermometer Adapter Included – 1022F/550C max temp readings
• Also measures Temperature via Temp Probe in Both F and C
• Milliseconds Pulse Width Measures Fuel Injector ON-TIME
• Inductive RPM Readings for both DIS and Conventional Ignitions
• Desirable 20 Amp Test Range – Dual Fuse Protection
• Modern Design, the Protective Holster is Built Into the Housing
• Data Hold, Auto Power-Off, + Trigger Adjust
• Large LCD Display w/White LED Backlighting and 40 Segment Analog Bargraph
• Blow Mold Case, Test Leads, IR Thermometer Adapter, K-Type Temp Probe, Inductive RPM Clamp and Instructions included

• AC/DC Voltage
• Resistance
• AC/DC Current
• Non-Contact IR Temp in F & C
• Temp via Contact Probe F & C
• RPM & (DIS) RPM
• Milliseconds Pulse Width
• Dwell (direct)
• Frequency (Hz)
• Duty Cycle
• Capacitance
• Diode Test
• Continuity

• AC Volts: 0-4V, 40V, 400V, 600V
• DC Amps: 0-40mA, 400mA, 20A
• AC Amps: 0-40mA, 400mA, 20A
• Ohms: 0-400, 4k, 400k, 400k, 4M, 40M,
• Capacitance: 0-4nF, 40nF, 400nF, 4uF, 400uF, 4mF, 40mF
• Frequency: 0-2kHz, 40kHz, 400kHz, 40MHz
• Duty Cycle: 0.1% – 99.9%
• Pulse Width: 1.0 – 20.0 ms
• Type K Temp: -22F to 1832F, -30C to 1000C
• IR Temp: -22F to 1022F, -30C to 550C
• RPM: 0-4000 RPM, 0-12000 RPM x10
• RPM (DIS): 0-4000 RPM, 0-6000 RPM x10
• Dwell: 4Cyl, 5Cyl, 6Cyl, 8Cyl
• Continuity: Continuity Beep – under 50 Ohms
• Diode: Diode Test
