Description
Electrical Specifications
| Specification | Value |
|---|---|
| Nominal Voltage | 12V |
| C20 | 20 Ah |
| C10 | 19 Ah |
| Short Circuit Current | 2000 Amps |
| CCA | 310 Amps |
| CA or MCA | 385 Amps |
| PHCA | 675 Amps |
| Internal Resistance | 5.9 mΩ |
Mechanical Specifications
| Specification | Value |
|---|---|
| Group Size | 20L |
| Terminal Type | M5TAS |
| Terminal Torque | 3.3 – 4.8 / 40 – 57.5 / 4.5 – 6.5 |
| Height (w/ terminal) | 6.12 in / 156 mm |
| Height (case only) | 6.12 in / 156 mm |
| Width | 3.42 in / 87 mm |
| Length | 6.89 in / 175 mm |
| Weight | 15.0 lbs / 6.8 kg |
| Case Type | ABS Plastic |
